Application
The mixer is suitable for mixing liquids containing suspended solids in sewage treatment and industrial processes.
Main materials: cast iron
Features
Compact structure, simple operation and maintenance, convenient installation and maintenance, long service life
The swept back blade has self-cleaning function, which can avoid entanglement and blockage
Motor insulation grade: F, protection class: IP68. High quality bearings and motor anti condensation devices adopted for ensuring safe operation
Two mechanical seals
Main technical parameters
Model | Power | Current | Impeller dia. | Impeller speed | Thrust | Weight | Installation system |
KW | A | mm | r/min | N | kg |
QJB0.85/8-260/3-740C | 0.85 | 3.1 | 260 | 740 | 165 | 65 | Ⅰ/Ⅱ |
QJB1.5/6-260/3-980C | 1.5 | 4 | 260 | 980 | 300 | 65 | Ⅰ/Ⅱ |
Q]B2.2/8-320/3-740C | 2.2 | 5.9 | 320 | 740 | 320 | 70 | Ⅱ |
QJB4/6-320/3-960C | 4 | 10.3 | 320 | 960 | 610 | 70 | Ⅱ |
